Rexroth A2FM series of A2FM10,A2FM12,A2FM16,A2FM23,A2FM28,A2FM32,A2FM45,A2FM56,A2FM63,
A2FM80,A2FM90,A2FM107,A2FM125,A2FM160,A2FM180,A2FM200,A2FM250,A2FM355,A2FM500
A2FM Axial piston ration motor features
1. oblique axial quantitative motor is suitable for hydrostatic drive of open circuit
2. applicable to the field of walking machinery or industry
3.the output flow is proportional to the driving speed and displacement
4. the design of its drive shaft bearing makes the appliion field reach the expected service life
5. multiple specifiions can match each actual drive
6. favorable power/weight ratio
7.compact and economical
8. optimum volumetric efficiency
9. integral plunger design with plunger ring
10.Top quality
11,competitive price
Description:
Axial piston unit of bent axis design with fixed displacement,for use as either pump or motor in hydrostatic drives,in open or closed circuit.
If operated as apump,the flow is proportional to the drive speed and displacement. if operated as a motor,the output speed is proportional to the swept volume and inversely paoportional to displacement.The output torque increases with the pressure drop between the high and low pressure sides
Special Features:
High performance rotary group with well-proven spherical control area with the advantages;self-centering low peripheral speed,high efficiency.
Robust rolling bearings endure long service life.
Drive shaft capable of adopting radial loading.
ISO mounting flange,uniform for fixed displacement pumps/motors and variable motors from size55.
May be used in conjunction with fire-resistant fluids.
low noises generation
